LED STRIPS | LINEAR LIGHTS PROFILES

ALUMINIUM PROFILE M-LINE REC 24 ST

1.2
PLASTIC COVERS Seite 236-237 / page 236-237

EINSCHUBPROFIL
SLIDING BASE
Years
SEE PAGE 37
M-LINE REC 24 ST (zum Wand- oder Deckeneinbau) M-LINE REC 24 ST (for wall or ceiling integration)
Vier verschiedene Formen von hochwertigen Kunststoff- Four different shapes of high quality plastic covers
abdeckungen stehen zur Verfügung: are available:
plan (nicht für DMX STRIP 30 geeignet), oval, halb- flat (not suitable for the DMX STRIP 30), oval, round
rund und eckig and square

Jede der vier Formen ist in glasklar, frost (halbklar) und Each of the four shapes are available in crystal clear,
milchig frost (opal) erhältlich. Die plane Abdeckung frost (semitransparent) and milky frost (opal). The flat
(FLAT) wird auch in schwarz (transluzenter Effekt) an- cover (FLAT) is also supplied in black (translucent
geboten. effect).
Auch ist die plane Abdeckung (FLAT) als begehbare The flat cover (FLAT) is also as a walkable and break-
und bruchfeste Variante in glasklar, frost (halbklar) proof version in crystal clear, frost and milky frost
und milchig frost (opal) erhältlich. (opal) available.
Produkttypen / Product Type

Artikel-Nr. Bezeichnung Länge
order code description length
EINSCHUBPROFIL L69C124 ALUMINIUM PROFILE M-LINE REC 24 ST 2 m
SLIDING BASE L69C124X ALUMINIUM PROFILE M-LINE REC 24 ST 3 m
L69C124Y ALUMINIUM PROFILE M-LINE REC 24 ST 5 m
L69C124Z ALUMINIUM PROFILE M-LINE REC 24 ST lfm (max. 5 m)* / per meter (max. 5 m)*
L69C124W ALUMINIUM PROFILE M-LINE REC 24 ST weiß / white** 2 m
L69C124WX ALUMINIUM PROFILE M-LINE REC 24 ST weiß / white** 3 m
L69C124WZ ALUMINIUM PROFILE M-LINE REC 24 ST weiß / white** lfm (max. 3 m)* / per meter (max. 3 m)*
L69C124B ALUMINIUM PROFILE M-LINE REC 24 ST schwarz / black*** 2 m
L69C124BX ALUMINIUM PROFILE M-LINE REC 24 ST schwarz / black*** 3 m
L69C124BZ ALUMINIUM PROFILE M-LINE REC 24 ST schwarz / black*** lfm (max. 3 m)* / per meter (max. 3 m)*
VERBINDER 24 / CONNECTOR 24 L690SBS ALUMINIUM SLIDING BASE M-LINE 2 m
90° L690SBSZ ALUMINIUM SLIDING BASE M-LINE lfm (max. 2 m)* / per meter (max. 2 m)*
L690SBSW ALUMINIUM SLIDING BASE M-LINE weiß / white** 2 m
LINEAR L690SBSWZ ALUMINIUM SLIDING BASE M-LINE weiß / white** lfm (max. 2 m)* / per meter (max. 2 m)*
L690SBSB ALUMINIUM SLIDING BASE M-LINE schwarz / black*** 2 m
L690SBSBZ ALUMINIUM SLIDING BASE M-LINE schwarz / black*** lfm (max. 2 m)* / per meter (max. 2 m)*
120°
ADJUSTABLE L690007 CONNECTOR 24 LINEAR
30°–330° L690008 CONNECTOR 24 90°
L690010 CONNECTOR 24 120°
135° L690011 CONNECTOR 24 135°
VERTICAL 90° L690012 CONNECTOR 24 VERTICAL 90°
L690017 CONNECTOR 24 ADJUSTABLE (Winkel einstellbar / angle adjustable)
L69C1S3E ALUMINIUM END CAP FLAT M-LINE REC 24 ST
L69C1S3EW ALUMINIUM END CAP FLAT M-LINE REC 24 ST weiß / white**
END CAP END CAP ARM L69C1S3EB ALUMINIUM END CAP FLAT M-LINE REC 24 ST schwarz / black***
L69C1S3EL ALUMINIUM END CAP FLAT M-LINE REC 24 ST HOLE
L69C1S3EWL ALUMINIUM END CAP FLAT M-LINE REC 24 ST HOLE weiß / white**
L69C1S3EBL ALUMINIUM END CAP FLAT M-LINE REC 24 ST HOLE schwarz / black***
L69C1S3EA ALUMINIUM END CAP FLAT ARM M-LINE REC 24 ST
L69C1S3EAW ALUMINIUM END CAP FLAT ARM M-LINE REC 24 ST weiß / white**
L69C1S3EAB ALUMINIUM END CAP FLAT ARM M-LINE REC 24 ST schwarz / black***
END CAP HOLE
L690003 ALUMINIUM PROFILE SPRING MOUNTING CLIP M-LINE / S-LINE
Wir empfehlen mindestens 3 Stück pro 2 m. / We suggest minimum 3 pcs per 2 m.
*Zuschnitt nach Maß / Custom Length ** weiß RAL 9016 / white RAL 9016 ***schwarz ähnlich RAL 9005 / black similar to RAL 9005
PLASTIC COVERS M-LINE Seite 236-237 / page 236-237
Formen Varianten
Eine Übersicht welche PROFILE mit welchen STRIPS shapes versions
kompatibel sind, finden Sie auf Seite 274. FLAT CLEAR, FROST, MILKY (OPAL), BLACK
BREAK-PROOF FLAT CLEAR, FROST, MILKY (OPAL)
OVAL CLEAR, FROST, MILKY (OPAL)
For compatibility of PROFILES and STRIPS see ROUND CLEAR, FROST, MILKY (OPAL)
page 274. SQUARE CLEAR, FROST, MILKY (OPAL)
