LED STRIPS | LINEAR LIGHTS PROFILES

ALUMINIUM PROFILE M-LINE STANDARD 24

1.2
PLASTIC COVERS Seite 236-237 / page 236-237

Years
SEE PAGE 37
M-LINE STANDARD 24 M-LINE STANDARD 24
Vier verschiedene Formen von hochwertigen Kunststoff- Four different shapes of high quality plastic covers
abdeckungen stehen zur Verfügung: are available:
plan (nicht für DMX STRIP 30 geeignet), oval, halb- flat (not suitable for the DMX STRIP 30), oval, round
rund und eckig and square
Jede der vier Formen ist in glasklar, frost (halbklar) und Each of the four shapes are available in crystal clear,
milchig frost (opal) erhältlich. Die plane Abdeckung frost (semitransparent) and milky frost (opal). The flat
(FLAT) wird auch in schwarz (transluzenter Effekt) an- cover (FLAT) is also supplied in black (translucent
geboten. effect).
Auch ist die plane Abdeckung (FLAT) als begehbare The flat cover (FLAT) is also as a walkable and break-
und bruchfeste Variante in glasklar, frost (halbklar) proof version in crystal clear, frost and milky frost
und milchig frost (opal) erhältlich. (opal) available.

EINSCHUBPROFIL / SLIDING BASE
EINSCHUBPROFIL
SLIDING BASE
Produkttypen / Product Type
Artikel-Nr. Bezeichnung Länge
order code description length
L690200 ALUMINIUM PROFILE M-LINE STANDARD 24 2 m
L690200X ALUMINIUM PROFILE M-LINE STANDARD 24 3 m
L690200Y ALUMINIUM PROFILE M-LINE STANDARD 24 5 m
L690200Z ALUMINIUM PROFILE M-LINE STANDARD 24 lfm (max. 5 m)* / per meter (max. 5 m)*
L690200W ALUMINIUM PROFILE M-LINE STANDARD 24 weiß / white** 2 m
L690200WX ALUMINIUM PROFILE M-LINE STANDARD 24 weiß / white** 3 m
L690200WZ ALUMINIUM PROFILE M-LINE STANDARD 24 weiß / white** lfm (max. 3 m)* / per meter (max. 3 m)*
L690200B ALUMINIUM PROFILE M-LINE STANDARD 24 schwarz / black*** 2 m
L690200BX ALUMINIUM PROFILE M-LINE STANDARD 24 schwarz / black*** 3 m
L690200BZ ALUMINIUM PROFILE M-LINE STANDARD 24 schwarz / black*** lfm (max. 3 m)* / per meter (max. 3 m)*
L690SBS ALUMINIUM SLIDING BASE M-LINE 2 m
L690SBSZ ALUMINIUM SLIDING BASE M-LINE lfm (max. 2 m)* / per meter (max. 2 m)*
VERBINDER 24 / CONNECTOR 24 L690SBSW ALUMINIUM SLIDING BASE M-LINE weiß / white** 2 m
90° L690SBSWZ ALUMINIUM SLIDING BASE M-LINE weiß / white** lfm (max. 2 m)* / per meter (max. 2 m)*
L690SBSB ALUMINIUM SLIDING BASE M-LINE schwarz / black*** 2 m
LINEAR L690SBSBZ ALUMINIUM SLIDING BASE M-LINE schwarz / black*** lfm (max. 2 m)* / per meter (max. 2 m)*
L690007 CONNECTOR 24 LINEAR
L690008 CONNECTOR 24 90°
120° L690010 CONNECTOR 24 120°
ADJUSTABLE
30°–330° L690011 CONNECTOR 24 135°
L690012 CONNECTOR 24 VERTICAL 90°
L690017 CONNECTOR 24 ADJUSTABLE (Winkel einstellbar / angle adjustable)
135° L6902S3E ALUMINIUM END CAP FLAT M-LINE STANDARD 24
VERTICAL 90°
L6902S3EW ALUMINIUM END CAP FLAT M-LINE STANDARD 24 weiß / white**
L6902S3EB ALUMINIUM END CAP FLAT M-LINE STANDARD 24 schwarz / black***
L6902S3EL ALUMINIUM END CAP FLAT M-LINE STANDARD 24 HOLE
L6902S3EWL ALUMINIUM END CAP FLAT M-LINE STANDARD 24 HOLE weiß / white**
L6902S3EBL ALUMINIUM END CAP FLAT M-LINE STANDARD 24 HOLE schwarz / black***
L6902R2E ALUMINIUM END CAP ROUND M-LINE STANDARD 24
L6902R2EW ALUMINIUM END CAP ROUND M-LINE STANDARD 24 weiß / white**
L6902R2EB ALUMINIUM END CAP ROUND M-LINE STANDARD 24 schwarz / black***
L6902S1E ALUMINIUM END CAP SQUARE M-LINE STANDARD 24
END CAP HOLE L6902S1EW ALUMINIUM END CAP SQUARE M-LINE STANDARD 24 weiß / white**
L6902S1EB ALUMINIUM END CAP SQUARE M-LINE STANDARD 24 schwarz / black***
*Zuschnitt nach Maß / Custom Length ** weiß RAL 9016 / white RAL 9016 ***schwarz ähnlich RAL 9005 / black similar to RAL 9005
PLASTIC COVERS M-LINE Seite 236-237 / page 236-237

Eine Übersicht welche PROFILE mit welchen STRIPS Formen Varianten
versions
shapes
kompatibel sind, finden Sie auf Seite 274. FLAT CLEAR, FROST, MILKY (OPAL), BLACK
BREAK-PROOF FLAT CLEAR, FROST, MILKY (OPAL)
For compatibility of PROFILES and STRIPS see OVAL CLEAR, FROST, MILKY (OPAL)
page 274. ROUND CLEAR, FROST, MILKY (OPAL)
SQUARE CLEAR, FROST, MILKY (OPAL)
proled.com 217
