PROFILES LED STRIPS | LINEAR LIGHTS

ALUMINIUM PROFILE SQ-LINE STANDARD 24

1.2
PLASTIC COVERS Seite 210-211 / page 210-211

Years
SEE PAGE 37
SQ-LINE STANDARD 24 SQ-LINE STANDARD 24
Eine plane Kunststoffabdeckung steht in fünf Varianten Flat plastic covers are available in following
EINSCHUBPROFIL HSB EINSCHUBPROFIL B zur Verfügung: versions:
SLIDING BASE HSB SLIDING BASE B glasklar, frost (halbklar), milchig frost (opal), mit Mikro- crystal clear, frost (semitransparent), milky frost (opal),
prismen und schwarz (transluzenter Effekt) with microprism and black (translucent effect)

EINSCHUBPROFIL HSB EINSCHUBPROFIL B
SLIDING BASE HSB SLIDING BASE B

Produkttypen / Product Type
Artikel-Nr. Bezeichnung Länge
VERBINDER 24 / CONNECTOR 24 order code description length
90° L69Q02S ALUMINIUM PROFILE SQ-LINE STANDARD 24 2 m
L69Q02SX ALUMINIUM PROFILE SQ-LINE STANDARD 24 3 m
LINEAR L69Q02SY ALUMINIUM PROFILE SQ-LINE STANDARD 24 5 m
L69Q02SZ ALUMINIUM PROFILE SQ-LINE STANDARD 24 lfm (max. 5 m)* / per meter (max. 5 m)*
L69Q02SW ALUMINIUM PROFILE SQ-LINE STANDARD 24 weiß / white** 2 m
120°
ADJUSTABLE L69Q02SWX ALUMINIUM PROFILE SQ-LINE STANDARD 24 weiß / white** 3 m
30°–330° L69Q02SWZ ALUMINIUM PROFILE SQ-LINE STANDARD 24 weiß / white** lfm (max. 3 m)* / per meter (max. 3 m)*
L69Q02SB ALUMINIUM PROFILE SQ-LINE STANDARD 24 schwarz / black*** 2 m
L69Q02SBX ALUMINIUM PROFILE SQ-LINE STANDARD 24 schwarz / black*** 3 m
135°
VERTICAL 90° L69Q02SBZ ALUMINIUM PROFILE SQ-LINE STANDARD 24 schwarz / black*** lfm (max. 3 m)* / per meter (max. 3 m)*
L69QSBS ALUMINIUM SLIDING BASE SQ-LINE HSB 2 m
L69QSBSZ ALUMINIUM SLIDING BASE SQ-LINE HSB lfm (max. 2 m)* / per meter (max. 2 m)*
L69QSBSW ALUMINIUM SLIDING BASE SQ-LINE HSB weiß / white** 2 m
L69QSBSWZ ALUMINIUM SLIDING BASE SQ-LINE HSB weiß / white** lfm (max. 2 m)* / per meter (max. 2 m)*
L69QSBB ALUMINIUM SLIDING BASE SQ-LINE B 2 m
L69QSBBZ ALUMINIUM SLIDING BASE SQ-LINE B lfm (max. 2 m)* / per meter (max. 2 m)*
L69QSBBW ALUMINIUM SLIDING BASE SQ-LINE B weiß / white** 2 m
L69QSBBWZ ALUMINIUM SLIDING BASE SQ-LINE B weiß / white** lfm (max. 2 m)* / per meter (max. 2 m)*
L690007 CONNECTOR 24 LINEAR
L690008 CONNECTOR 24 90°
L690010 CONNECTOR 24 120°
L690011 CONNECTOR 24 135°
L690012 CONNECTOR 24 VERTICAL 90°
L690017 CONNECTOR 24 ADJUSTABLE (Winkel einstellbar / angle adjustable)
L69QS3SE ALUMINIUM END CAP FLAT SQ-LINE STANDARD
L69QS3SEW ALUMINIUM END CAP FLAT SQ-LINE STANDARD weiß / white**
L69QS3SEB ALUMINIUM END CAP FLAT SQ-LINE STANDARD schwarz / black***
*Zuschnitt nach Maß / Custom Length ** weiß RAL 9016 / white RAL 9016 ***schwarz ähnlich RAL 9005 / black similar to RAL 9005

Eine Übersicht welche PROFILE mit welchen STRIPS PLASTIC COVERS SQ-LINE Seite 210-211 / page 210-211
kompatibel sind, finden Sie auf Seite 274.
Formen Varianten
shapes versions
For compatibility of PROFILES and STRIPS see FLAT CLEAR, FROST, MILKY (OPAL), MICROPRISM, BLACK
page 274.
